Product specifications: length 1000 * width 1000 * height 1900mm.

Product material: body made of gold plate.

Product power: 220VCA 500W

Compressed air: 6Bar, 40L/min. Humidity is not more than 60%, compressed air must be dried, free of dust and corrosive gas

Operator: 1 person

Inspection content: ①External circle diameter and inner hole diameter detection, ②360-degree ring shot detection of inner wall and outer wall defects, ③Lack of material detection on the inner and outer circle edges, ④Surface defect detection, ⑤Hole plugging detection, ⑥Inside and outer circle burr detection

Detection efficiency: up to 18000PCS/hour
